Tripp Lite UPS, ENERGY STAR certified
Tripp Lite AG-87C1
600 VA / 60 W passive standby UPS, model number ECO1000LCD.
Capacity
600 VA
60 W real power
Topology
Passive Standby
Efficiency
98.6%
weighted, as tested
Runtime @ 50%
7 min
2 min at full load
A UPS has two ratings and the lower one is the limit. This unit is rated 600 VA and 60 W, so the equipment plugged into its battery outlets should draw no more than about 48 W if you want the usual 20% headroom. How to size a UPS.
Its weighted efficiency of 98.6% compares with a median of 98.6% across 98 certified units within 25% of its capacity. With nothing plugged in it still draws 0.4 W, about $0.42 a year at 13¢/kWh just to stand ready.
- Maker
- Tripp Lite
- Model
- AG-87C1
- Model number
- ECO1000LCD
- Apparent power rating
- 600 VA
- Real power rating
- 60 W
- Power factor
- 0.10
- Topology
- Passive Standby
- Intended use
- Consumer, Commercial
- Battery
- Valve Regulated Lead-acid Battery
- Runtime at 50% load
- 7 min
- Runtime at 100% load
- 2 min
- Battery warranty
- 3 yr
- Weighted efficiency
- 98.6%
- Efficiency at 25 / 50 / 75 / 100% load
- 97.9% / 98.8% / 98.4% / 98.6%
- Input power at no load
- 0.4 W
- Outlets
- 8 (4 battery + surge, 8 surge only)
- Rack mountable
- No
- Rated input voltage
- 120 V
- Rated output voltage
- 120 V
- Connections
- USB Port,Ethernet
- Size (H x W x D)
- 279 x 99 x 288 mm
- Maker take-back program
- Yes
- On the market since
- Apr 2018
- ENERGY STAR certified
- 7 Aug 2018
Source: ENERGY STAR certified uninterruptible power supplies dataset, US EPA, record 2334236, data build 2026-09-29. Figures are as the maker certified them. How we use this data.
